ONE XXL Podcast by Studiobricks

ONE XXL Podcast by Studiobricks

A$0.00

Set Yourself Free!

Ideal for podcasts and vcasts. Room for two!

A compact solution for talk & record whenever you want. Studiobricks Podcast One gives you the the professional equipment you need to create high quality broadcasts.

Compact sound isolation studio designed for the home or offices.

Spacious on the inside and unimposing from the out. Convert any space in a professional recording studio.

Ecofriendly materials.

Fireproof and ecological insulation and acoustic treatment based on 100% recycled cotton and PET. NAF MDF. No use of mineral wool or foams.

Quick and easy to assemble

Add To Cart

Spec Sheet - One XXL Podcast

Measurements

Outside (WxLxH) 121 x 198 x 226 cm (3.97 x 6.50 x 7.41 ft)

Inside (WxLxH) 105 x 180 x 210 cm (3.44 x 5.90 x 6.89 ft)

Minimum ceiling height - 232 cm (7.61 ft)

Weight - 640 kg (1,411 lb)

Minimum distance from room’s walls - 5 cm (2 in)

Standard Configuration

• Recording equipment - Podcast setup (stools are optional)

• Studiobricks CBTrap3080 bass trap (1 unit): Light gray | Recycled PET.

• Hinged desk: 60 x 60 cm (23,6 x 23,6 in)

• 2x Yellowtech m!ka MMS Wall Mount Pole (YT3260): 17“ (432mm) | aluminium | With mounting holes

• 2x Yellowtech m!ka Microphone Arm M Aluminium (YT3201): Max length 31” (78,7cm) | Max mic weight: 4.41 lbs (2kg)

• 2x Yellowtech m!ka MMS Pole Adapter (YT3213): Aluminium | Plug-in mount for m!ka arms to m!ka Poles

• Yellowtech m!ka Monitor Arm M (YT3230): Aluminium | Max range 19,9” (50,5cm) | Up to 33lbs (15kg)

• Yellowtech m!ka CopyStand XL (A3) with QuickFix (YT3272): Transparent Perspex® | For m!ka Monitor Arm

• SmartFuser diffuser 2 units (16 pieces). Black or white

Exterior color White (RAL 9016)

Interior color White (RAL 9016)

Acoustic absorbers (wall) Studiobricks Eco45 (light gray):

100% recycled PET absorbers (thermally bonded, without chemical binders). Best absorbption ever reducing reverb time thanks to its 45 mm thickness and its 25 kg / m3 density. Absorption class: C (0,60 to 0,75 αw) (UNE-EN ISO 11654:1998)

Acoustic absorber (ceiling) Studiobricks EcotexOne (light gray): 100% Recycled PET felt based on recycled vegetable cotton bras panel. Thickness (cm/in): 20 mm (+/-0,2) / 0,8 in (+/-0,08). Density: 60 kg/m3 (+/-10%). Absorption class: A (0,90 αw) (BS EN ISO 1654:1997)

Sound control glass door 75 x 210 cm (2.5 x 6.9 ft), opening to the outside. Aluminum framewith a block of silent laminated safety glass and temperature/ sound edge spacer and air chamber: 3+3+16+5+5 mm (0.1+0.1+0.6+ 0.2+0.2 in). Acoustic sealing. Textured Anthracite gray.

Soundproof ventilation kit Adjustable intensity levels, extremely quiet and easy filter exchange.

Acoustic cable tunnel Up to 10 cables

Secondary acoustic cable tunnel Up to 5 cables

Lighting Studiobricks Light Panel 120 LED light

Carpet Dark gray (deburred)
